使用Netty和阿里云函数写一个低成本的“梯子”
2018-10-23Backend

函数计算(Function Compute)是事件驱动的全托管计算服务。函数计算无需租用和管理24小时运行的服务器(Serverless),无需搭建复杂的服务器环境,只需编写代码并上传就可以了,只需要为代码实际运行消耗的资源付费,非常便宜。
<!--more-->函数计算可以选择运行区域,也就是说,我们可以将函数运行的服务器区域选择到香港或者是美国,如此会带来什么样的好处,只可意会,不可言传。那么能否利用云函数写一个Proxy软件呢?请看本文!
在阿里云上新建函数计算
我们需要建立一个云函数,和一个HTTP触发器。
此过程请参考阿里云官网,我就不详细赘述。官网在此
Netty服务端Handle代码
package cn.wycode.lambda.proxy.inbound
import cn.wycode.lambda.proxy.config.AliyunConfig
import cn.wycode.lambda.proxy.outbound.ProxyOutboundInitializer
import io.netty.bootstrap.Bootstrap
import io.netty.buffer.ByteBuf
import io.netty.buffer.Unpooled
import io.netty.channel.*
import io.netty.handler.codec.http.*
import io.netty.util.CharsetUtil
class ProxyInboundHandler(val aliyunConfig: AliyunConfig) : SimpleChannelInboundHandler<ByteBuf>() {
// As we use inboundChannel.eventLoop() when building the Bootstrap this does not need to be volatile as
// the outboundChannel will use the same EventLoop (and therefore Thread) as the inboundChannel.
private var outboundChannel: Channel? = null
override fun channelRead0(ctx: ChannelHandlerContext, msg: ByteBuf) {
println("ProxyInboundHandler<<<" + msg.toString(CharsetUtil.UTF_8))
// val headers = msg.headers()
// val headerMap = HashMap<String, String>(headers.size())
// headers.forEach { headerMap[it.key] = it.value }
// val outboundBody = Request(msg.method().name(), msg.uri(), msg.protocolVersion().text(), headerMap)
// val outboundJson = JSON.toJSONString(outboundBody)
val request = DefaultFullHttpRequest(HttpVersion.HTTP_1_1, HttpMethod.POST, aliyunConfig.path)
request.headers().set(HttpHeaderNames.HOST, aliyunConfig.host)
request.headers().set(HttpHeaderNames.CONNECTION, HttpHeaderValues.CLOSE)
request.headers().set(HttpHeaderNames.CONTENT_TYPE, HttpHeaderValues.APPLICATION_JSON)
request.headers().set(HttpHeaderNames.CONTENT_LENGTH, msg.writerIndex())
// request.content().writeCharSequence(outboundJson, CharsetUtil.UTF_8)
request.content().writeBytes(msg)
//
if (outboundChannel!!.isActive) {
println("ProxyInboundHandler>>>${request.content().toString(CharsetUtil.UTF_8)}")
outboundChannel!!.writeAndFlush(request).addListener(object : ChannelFutureListener {
override fun operationComplete(future: ChannelFuture) {
if (future.isSuccess) {
// was able to flush out data, start to read the next chunk
ctx.channel().read()
} else {
future.channel().close()
}
}
})
}
}
override fun channelActive(ctx: ChannelHandlerContext) {
val inboundChannel = ctx.channel()
// Start the connection attempt.
val outboundClient = Bootstrap()
outboundClient.group(inboundChannel.eventLoop())
.channel(inboundChannel.javaClass)
.handler(ProxyOutboundInitializer(inboundChannel))
.option(ChannelOption.AUTO_READ, false)
val f = outboundClient.connect(aliyunConfig.host, aliyunConfig.port)
outboundChannel = f.channel()
f.addListener { future ->
if (future.isSuccess) {
// connection complete start to read first data
inboundChannel.read()
} else {
// Close the connection if the connection attempt has failed.
inboundChannel.close()
}
}
}
override fun channelInactive(ctx: ChannelHandlerContext) {
if (outboundChannel != null) {
closeOnFlush(outboundChannel!!)
}
}
override fun exceptionCaught(ctx: ChannelHandlerContext, cause: Throwable) {
cause.printStackTrace()
closeOnFlush(ctx.channel())
}
companion object {
fun closeOnFlush(ch: Channel) {
if (ch.isActive) {
ch.writeAndFlush(Unpooled.EMPTY_BUFFER).addListener(ChannelFutureListener.CLOSE)
}
}
}
}
Netty客户端Handle代码
package cn.wycode.lambda.proxy.outbound
import cn.wycode.lambda.proxy.inbound.ProxyInboundHandler
import io.netty.channel.*
import io.netty.handler.codec.http.FullHttpResponse
import io.netty.util.CharsetUtil
class ProxyOutboundHandler(private val inboundChannel: Channel) : SimpleChannelInboundHandler<FullHttpResponse>() {
override fun channelActive(ctx: ChannelHandlerContext) {
println("ProxyOutBoundHandle==")
ctx.read()
}
override fun channelRead0(ctx: ChannelHandlerContext, msg: FullHttpResponse) {
println("ProxyOutBoundHandle<<<$msg")
val body = msg.content().toString(CharsetUtil.UTF_8)
println("ProxyOutBoundHandle body<<<$body")
// val proxyResponse = try {
// JSON.parseObject(body, Response::class.java)
// } catch (e: Exception) {
// e.printStackTrace()
// msg.retain()
// inboundChannel.writeAndFlush(msg).addListener(object : ChannelFutureListener {
// override fun operationComplete(future: ChannelFuture) {
// if (future.isSuccess) {
// // was able to flush out data, start to read the next chunk
// ctx.channel().read()
// } else {
// future.channel().close()
// }
// }
// })
// return
// }
// val headers = CombinedHttpHeaders(true)
// var outBytes:ByteArray? = null
// if (proxyResponse.error == null) {
// for (header in proxyResponse.headers!!) {
// headers[header.key] = header.value
// }
// outBytes = Base64.getDecoder().decode(proxyResponse.content)
// }else{
// outBytes = proxyResponse.error.toByteArray()
// }
// val response = DefaultFullHttpResponse(HttpVersion.HTTP_1_1,
// HttpResponseStatus.valueOf(proxyResponse.code),
// Unpooled.wrappedBuffer(outBytes),
// headers, DefaultHttpHeaders())
msg.retain()
inboundChannel.writeAndFlush(msg.content()).addListener(object : ChannelFutureListener {
override fun operationComplete(future: ChannelFuture) {
if (future.isSuccess) {
// was able to flush out data, start to read the next chunk
ctx.channel().read()
} else {
future.channel().close()
}
}
})
}
override fun channelInactive(ctx: ChannelHandlerContext) {
println("ProxyOutBoundHandle!=")
ProxyInboundHandler.closeOnFlush(inboundChannel)
}
override fun exceptionCaught(ctx: ChannelHandlerContext, cause: Throwable) {
cause.printStackTrace()
ProxyInboundHandler.closeOnFlush(ctx.channel())
}
}
云函数代码
package cn.wycode.lambda;
import com.aliyun.fc.runtime.Context;
import com.aliyun.fc.runtime.FunctionComputeLogger;
import com.aliyun.fc.runtime.StreamRequestHandler;
import java.io.*;
import java.net.Socket;
import java.net.URL;
import java.nio.charset.StandardCharsets;
public class Lambda implements StreamRequestHandler {
@Override
public void handleRequest(InputStream input, OutputStream output, Context context) throws IOException {
FunctionComputeLogger logger = context.getLogger();
StringBuilder sb = new StringBuilder();
byte[] buffer = new byte[1024];
int n;
while ((n = input.read(buffer)) != -1) {
sb.append(new String(buffer, 0, n, StandardCharsets.UTF_8));
}
logger.info("handleRequest>>>" + sb.toString());
String firstLine = new BufferedReader(new StringReader(sb.toString())).readLine();
String host;
int port;
try {
if (firstLine.startsWith("CONNECT ")) {
String[] urlArray = firstLine.split(" ")[1].split(":");
host = urlArray[0];
port = Integer.parseInt(urlArray[1]);
} else {
URL url = new URL(firstLine.split(" ")[1]);
host = url.getHost();
port = url.getPort();
if (port == -1) {
if (url.getProtocol().equalsIgnoreCase("http")) {
port = 80;
} else if (url.getProtocol().equalsIgnoreCase("https")) {
port = 443;
} else {
throw new IllegalArgumentException("端口无法解析");
}
}
}
} catch (Exception e) {
logger.error("url解析错误:" + e.getMessage());
return;
}
logger.info("host->" + host);
logger.info("port->" + port);
Socket s = new Socket(host, port);
if (firstLine.startsWith("CONNECT ")) {
String response = "HTTP/1.1 200 Connection Established";
output.write(response.getBytes(StandardCharsets.UTF_8));
output.flush();
sb.setLength(0);
while ((n = input.read(buffer)) != -1) {
sb.append(new String(buffer, 0, n, StandardCharsets.UTF_8));
}
logger.info("handleRequest>>>" + sb.toString());
}
OutputStream httpOutputStream = s.getOutputStream();
httpOutputStream.write(sb.toString().getBytes(StandardCharsets.UTF_8));
InputStream httpInputStream = s.getInputStream();
sb.setLength(0);
while ((n = httpInputStream.read(buffer)) != -1) {
output.write(buffer, 0, n);
sb.append(new String(buffer, 0, n, StandardCharsets.UTF_8));
}
httpInputStream.close();
httpOutputStream.close();
s.close();
input.close();
output.close();
logger.info("handleRequest<<<" + sb.toString());
}
}
遗留问题
- HTTP请求代理测试通过
- 可以在Netty客户端发送请求时,对请求体进行二进制加密,函数端解密;函数端收到真实响应加密,Netty客户端收到请求后解密。从而提高安全性
- 对于HTTP请求头为
Connection:keep-alive
的请求,函数端在读取真实响应时,会阻塞在流末尾的read方法而无法返回结果,Connection:close
的请求正常 - HTTPS请求在有代理的情况下,浏览器会先发送一个HTTP CONNECT请求,以建立TSL通道。目前因为read阻塞问题还没有解决。
附:本项目全部源码地址:
Netty端:https://github.com/wangyucode/lambda-cross-java 函数端:https://github.com/wangyucode/aliyun-lambda
